| Place of Origin: | Chongqing, China |
|---|---|
| Brand Name: | ADJIG |
| Model Number: | RME |
| Document: | RME.pdf |
| Minimum Order Quantity: | 1 |
| Price: | 1324 USD per item |
| Packaging Details: | Carton/wooden crate |
| Delivery Time: | 7-10 days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Less than 10 pieces, shipped within 10 days. More than 10 items will be shipped within 30 days. |
| Unlock Method: | Pneumatic Pressure | Locking Method: | Mechanical Locking |
|---|---|---|---|
| Unlock Pressure: | 0.6MPa | Material: | Stainless Steel And Alumina |
| Repeatability: | 0.02mm | Weight(kg): | 1.6kg |
| Clamping Force (kN): | 4 | Maximum Torque (N-m)(x): | 600 |
| Maximum Torque (N-m)(z): | 1600 | Application: | Automated Multi-axis Robotic Handling Operations |
| Highlight: | 0.6MPa Automated Fixtures,NSR Automated Fixtures,Robot Couplings for Automation Systems |
||
NSR Robot Modules and High-Precision Robot Couplings for Flexible Automation Systems
Product features:
Material: aluminum oxide;
Takes up less space during use, maximizes space utilization, and works with robotic arm couplings.
Applicable industries: Suitable for automated multi-axis robot handling operations.
NSR Robot Modules and High-Precision Couplings deliver exceptional performance for flexible automation systems. Engineered for reliability and micron-level repeatability, these components enable seamless integration and rapid reconfiguration of robotic workcells. The robust couplings maintain perfect alignment under high loads, ensuring vibration-free operation for precision tasks. Their modular design allows for scalable system expansion and easy maintenance, significantly reducing downtime. Compatible with major robot brands, these solutions support advanced manufacturing processes and Industry 4.0 initiatives. Ideal for machining, assembly, and inspection applications, they provide the foundational elements for building efficient, future-proof automated systems with unmatched accuracy and durability.
| Part Number | Size Number | Unlock Method | Clamping Force(KN) | Maximum Torque(N.m)x | Maximum Torque(Nm)z | Weight(kg) | ||||||||
| RME | R20 | Pneumatic Pressure | 4 | 600 | 1600 | 1.6 | ||||||||
| Size Number | A | B | DN | D1 | D2 | D3 | H | H1 | H2 | H3 | K | M1 | M2 | N |
| R20 | 125 | 52 | 159 | 142 | 104 | 96 | 62 | 26 | 47 | 65 | 32 | M8 | M8 | 10 |
![]()
