Precision Split V Block Accurate Holding Machining For Round Workpieces
| MOQ: | 5 |
| Price: | 126-168 USD per item |
| Standard Packaging: | Carton/Wooden crate |
| Delivery Period: | 7-10 days |
| Payment Method: | L/C,T/T |
| Supply Capacity: | Less than 20 pieces, shipped within 10 days. More than 20 items will be shipped within 15-20 days. |
Precision Split V Block Accurate
,Split V Block Holding
,Workpieces Fixture Support Components
Precision Split V Block for Accurate Holding and Machining of Round Workpieces
Material: S45C
Heat Treatment: HRC45
Surface Finish: Blackened
Application: Combined with SU15 to form a V-block.
Support range can be adjusted appropriately based on workpiece dimensions using the alignment holes.
Elevate your precision machining with this essential Precision Split V Block, engineered for the secure and accurate holding of round workpieces. Its innovative split design allows for versatile top and side clamping, ensuring your cylindrical parts—from shafts to pins—are held firmly and concentrically for drilling, milling, and grinding operations. Manufactured from high-grade, hardened steel and meticulously ground to exacting tolerances, it guarantees long-lasting durability and repeatable accuracy. The integrated clamping slots provide seamless compatibility with standard fixture sets. This indispensable tool drastically reduces setup time while eliminating misalignment, making it a cornerstone for any high-accuracy machining or inspection task.
| Model No. | A | B | C | D | E | F | KG | |
| Max | Min | |||||||
| SU14-1250-600 | 12 | M12 | 22 | 85 | 80 | 600 | 50 | 1.85 |
| SU14-1650-600 | 16 | M16 | 16 | 85 | 80 | 600 | 50 | 1.76 |
