Compact Manual Hold Down Fixture Clamps OEM Fixture Clamps Cnc

Compact Custom Manual Workholding Fixture for Precision CNC Workholding Clamping

The fixture is mounted on a heavy-duty rotary table that provides rotational positioning for multi-face machining. The central workpieces are held by a combination of fixed stops, clamping blocks, and precision locating features. The light blue clamp modules are arranged symmetrically to maintain balanced cutting forces during machining. The fixture plate includes multiple tapped holes for flexible reconfiguration, supporting different part geometries without redesigning the entire system. This setup is engineered for repeatability, reducing human error and ensuring consistent positioning for every part loaded. It is an efficient solution for high-mix, low-volume machining tasks.
