Swing Clamp CP08 Hook Type Fixture Hook Clamps For Easy Loading When Top Clamping
| MOQ: | 3 |
| Price: | 30-42 USD per item |
| Standard Packaging: | Carton/wooden crate |
| Delivery Period: | 7-10 days |
| Payment Method: | T/T,L/C |
| Supply Capacity: | Less than 30 pieces, shipped within 5-7 days. More than 30 items will be shipped within 25-30 days. |
s45c slotted mould clamp
,s45c fixture clamping pressure plate
Swing Clamp CP08 Hook Type Fixture Hook Clamps For Easy Loading When Top Clamping
Swing clamps allow the Workholding to be moved out of the way for Easy Loading
Ground and Threaded Toe allows for use of Inserts
Fixed on the base plate or pedestal, used for clamping workpieces.
Easy disassembly and assembly of workpieces, the pressure plate part can rotate, and the upper and lower workpieces are not interfered with.
Material: SCM-4
CP08 Swing clamps are useful for supplying a good amount of holding force. From a clamp using a small amount of surface area. Like most of Leave's components it can be used well with the rest of the fixturing components and base plates. Swing clamps allow for the workholding to be swung out the way to allow for easy loading of components.
| Model | A | B | C | D | E | F | G | H | I |
weight (kg) |
| CP08-1240-29 | 30 | 28 | 16 | 40 | * | M12 | 29 | * | 22 | 0.29 |
| CP08-1245-36 | 50 | 32 | 20 | 45 | 40 | M12 | 36 | M12 | 26 | 0.5 |
| CP08-1645-36 | 50 | 32 | 20 | 45 | 40 | M16 | 36 | M12 | 26 | 0.5 |
| CP08-1645-41 | 60 | 40 | 45 | 45 | 45 | M16 | 41 | M16 | 32 | 0.75 |
